4 Daily Maintenance
4-24
Wiper cleaning
Bring the wiper into the wiper box and wash the wiper.
Washing will not be started if the cleaning liquid has not been supplied or the cleaning liquid cartridge has not
been installed.
STEPS:
1Make sure that the printer is in LOCAL mode, and then press the [ST.MAINT] key.
If it is in REMOTE mode, press the [REMOTE] key.
2Select [WIPER WASH] by pressing the [] key five times and press the [ENTER] key.
3The cleaning solution is dripped onto the wiper.
After completion of the dripping, the carriage moves to above the platen.
Before executing the [WIPER WASH] function, the tubes must be filled with the
cleaning solution. For how to fill the tubes with the cleaning solution, refer to
following page.
(Refer to “ Before executing the [PUMP TUBE WASH] (p. 4-19)” )
The following display will appear if supply of cleaning liquid is required.
L. ∗ > [JV5-01]
width : ∗∗∗∗ mm
ST.MAINTENANCE
CARRIAGE OUT <ent>
6
times
ST.MAINTENANCE
WIPER WASH <ent>
Fill with the maint.
washing liquid.
∗ ∗ ∗ ∗ ∗ ERROR 30 ∗ ∗ ∗ ∗ ∗
OPERATION ERROR
WASHING
PLEASE WAIT
WIPER WASH
∗ ∗ ∗ ∗ ∗ ∗ ∗ − − − − − − − − − − −
To Next Page
