3-9
Setting the media on the printer
Setting roll media on the printer
The procedure for setting roll media on the printer is described below.
Installation procedure
1Raise the clamp lever in the front of the printer.
2Loosen the screw securing the left roll holder, and determine the position of the roll
holder.
The roll media is heavy in weight. Take care not to drop it on your foot.
Also take care not to throw out your back.
Take care in operating the Clamp Lever.
If the Clamp Lever is handled carelessly, you can get injuried as a result of an
impact caused by the lowered Clamp Lever.
The inside diameter of the roll media core is 2 inches or 3 inches.
Clamp lever
Roll holder securing screw
To Next Page
