4 Daily Maintenance
4-42
When the waste ink tank is full
Waste ink, which was used for cleaning the heads and other parts, gathers in the waste ink tank.
When either of the following error message is displayed, replace the waste ink tank with a new one without
delay.
STEPS:
1Remove the screw for the waste ink tank guard and open the waste ink tank guard.
2Raise the waste ink tank by holding the larger handle. With the tank raised, turn the
tank by 90 degrees. Then pull the tank down and toward you.
3Replace the waste ink tank with a new one.
By holding the handle, insert the new tank. Put the cap on the tank that is full of waste ink and dispose of the
tank.
Use only the waste ink tank dedicated for JV5 (SPC-0128).
If any tank other than the dedicated one is used, the remaining capacity for
waste ink cannot be detected properly, so that waste ink may leak out from the
tank.
When pulling out the waste ink tank, hold the opening of the waste ink tank with
paper and then slowly pull it out with care not to let waste ink spatter out.
Before replacing the waste ink tank, spread a sheet of paper on the floor to pre-
vent it from being stained with ink.
L .1 > [ JV5-01 ]
! WasteTANK FULL/NONE
L .1 > [ JV5-01 ]
! NearFULL WASTE TANK
To Next Page
