© 2009 MIMAKI ENGINEERING CO.,LTD.
Maintenance Manual Contents R.1.2 P.2
Maintenance Manual > Maintenance Manual Contents
Model CJV30/TPC Issued 2008.08.04 Revised 2009.08.27 F/W ver. 2.00 Remark
Maintenance Manual Contents
1.2
4.2.15 PRINT/CUT POS.
4.2.16 SERIAL No.
4.2.17 DEALER No.
4.2.18 DEFAULT SET
4.2.19 REPLACE PARTS
4.3 Mechanical Adjustment
4.3.1 Adjusting the Location of Mark Sensor
4.3.2 Adjustment of the Mounting Location
for the Cutter
4.3.3 Adjustment of the Station Height
4.3.4 Adjustment of the Wiper Height
4.3.5 Positioning of the Encoder Sensor
4.3.6 Centering of the Roll Holder
4.3.7 Positioning of the Wiper Drive Link
5 Test Items
5.1 Test Function
5.1.1 [CHECK PATTERN] PATTERN
5.1.2 [CHECK PATTERN] COLOR
CHART
5.1.3 [CHECK PATTERN] DROP.POS
CHK
5.1.4 ALL PATTERN
5.1.5 [MOTOR TEST] X SERVO MOTOR
5.1.6 [MOTOR TEST] Y SERVO MOTOR
5.1.7 [MOTOR TEST] XY SERVO
MOTOR
5.1.8 [MOTOR TEST] WIPER MOTOR
5.1.9 [MOTOR TEST] PUMP MOTOR
5.1.10 [MOTOR TEST] TAKE-UP MOTOR
5.1.11 [HEATER TEST] TEMPERATURE
5.1.12 [HEATER TEST] SSR
5.1.13 ACTION TEST
5.1.14 SENSOR TEST
5.1.15 OPTION
5.1.16 KEYBOARD LED
5.1.17 KEYBOARD TEST
5.1.18 LCD TEST
5.1.19 TIMER CHECK
5.1.20 MEMORY CHECK
5.1.21 SKEW CHECK
5.1.22 [TEMP.CHECK] HEAD TEMP.
5.1.23 [TEMP.CHECK] NOZZLE TEMP.
5.1.24 [TEMP.CHECK] HEAT SINK TEMP.
5.1.25 [TEMP.CHECK] SLIDER TEMP.
5.1.26 LINEAR ENCODER
5.1.27 [INK CARTRIDGE] PACK&END
SENSOR
5.1.28 [INK CARTRIDGE] CARTRIDGE
VALVE
5.1.29 [INK CARTRIDGE] INK-IC CHECK
5.1.30 [INK CARTRIDGE] CARTRIDGE
LED
5.1.31 [WASH CARTRIDGE] PACK&END
SENSOR
5.1.32 [WASH CARTRIDGE] CARTRIDGE
VALVE
5.1.33 [WASH CARTRIDGE] IC CHECK
5.1.34 HEAD JOINT
5.1.35 PINCH ROLLER
5.1.36 [CUT PATTERN] TEST
5.1.37 [CUT PATTERN] 2m
5.1.38 [CUT PATTERN] 10m
5.1.39 [CUT PATTERN] QUALITY
5.1.40 [CUT PATTERN] SQUARE
5.2 Other Test
5.2.1 Determining COM short circuit
5.2.2 Checking Damage of the Print Heads
5.2.3 Checking Damage of the Main PCB
ASSY
5.2.4 Checking Damage of the Ink Slider
PCB
5.2.5 Checking Conduction of HDC FFC
COM Line
5.2.6 Checking Conduction of HDC FFC
Data Line
6 Disassembly and Reassembly
6.1 Covers
6.1.1 Cover Layout
6.2 Ink-related Parts
6.2.1 Cleaning the inside of Head Unit
6.2.2 Removing of Head Unit
6.2.3 Mounting of Head Unit
6.2.4 Pump Motor
6.2.5 Pump Assy
6.2.6 Cap Assy
6.2.7 Cap Head Assy
6.2.8 Valve Assy
6.2.9 Changing Joint
6.3 Cut Head Carriage
6.3.1 Pen Assy and LED Pointer
6.3.2 Auto Cutter Assy
6.3.3 Mark Assy
6.4 Drive System
6.4.1 X-axis Motor
6.4.2 Y-axis Motor
6.4.3 Y Drive Pulley
6.4.4 Y Drive Belt
6.4.5 Linear Encoder Scale
6.4.6 Wiper Unit
6.4.7 GR Roller Assy
6.4.8 Take-up Motor
6.4.9 C Connecting Hook
6.4.10 P Head Connecting Hook
6.4.11 Clamp Assy
6.5 Electrical Parts
