A7™ Service Manual 046-006272-00 2 - 7
Installation Guide Assembly
FIGURE 2-8 Canada only
10. At the base of the box platform, remove both sets of orange straps.
FIGURE 2-9
11. Remove the piece of wood at the front of the A7. Then, remove the foam packing material from
around the front of the unit.
FIGURE 2-10
12. Remove the foam packing material from around the back of the unit.
Vacuum suction packing box
Two battery packing boxes
