A7™ Service Manual 046-006272-00 1 - 5
Theory of Operation Electrical and Pneumatic Connections
No. Description P/N
B1 Power Board (A7) 115-018145-00
B2 Battery Interface Board 801-0631-00109-00
B3 CPU Board 115-040636-00
B4 IndicatorLight Board 051-001257-00
B5 Infrared Communication Board 801-0621-00165-00
B6 Anesthesia Signal Interface Board 801-0613-00033-00
B7 Display Interface Board 051-001258-00
B8 Backlight Inverter Board
051-001519-00 (old)
051-002583-00 (new)
B9 Warning Light Board 801-0631-00019-00
B10 Touchscreen Control Board 801-0631-00018-00
B11 Encoder Board 051-001260-00
B12 Flow Meter Lighting Board
Part of 115-018165-
00(FDA)
Part of 115-018166-
00(Canadian)
B13 Top Lighting Board 801-0631-00039-00
B14 Mother Board
051-001259-00
051-002662-00 (VGA)
B15-16 Ventilator Control Board 801-0631-00027-00
B17 Sensor Interface Board 801-0631-00089-00
B18 Electronic Flow Control System (EFCS) Monitor Board 115-018150-00
B19 Air Flow Sensor Interface Board 051-001415-01
B20 Nitrous Oxide Flow Sensor Interface Board 051-001416-01
B21-22 O2 Flow Sensor Interface Board 051-001414-01
B23 Total Flow Meter Backlight Board Part of 115-014479-00
B24 BFCS Position Board 051-001286-01
P1 Filter Power 250VAC 15A Panel Mount 801-0631-00029-00
P2 Breaker(10.0A) 801-0631-00030-00
P3-6 Breaker(3.0A) 801-0631-00031-00
P7-10 Auxiliary Output Socket 801-0631-00032-00
P11 Speaker and Connecting cable 801-0631-00038-00
P12 Hardware Box Fan 801-0631-00028-00
P13-14 Lithium-ion Battery 115-018012-00
P15 Button Cell M05-010R03---
P16 Touchpad 801-0631-00052-00
P17 Gas Bench Fan 024-000407-00
P18 Touch Screen 801-0631-00014-00
P19 LCD 115-039181-00
P20-21 Rotary Encoder 010-000150-00
P22 Cable, Lighting Switch 009-000981-00
P23 Circuit Heater 115-034450-00
C1-4 Cable, Power, AC Internal 009-000985-01
To Next Page
