Electrical and Pneumatic Connections Theory of Operation
1 - 6 046-006272-00 A7™ Service Manual
C5 Cable, Auxiliary Outlet 009-000984-00
C6 Cable, AC power 009-000983-00
C8 Cable, Indicator 009-000977-00
C9 Cable, System Switch 009-001776-00
C10 Cable, Touchpad 009-000972-00
C11 Cable, Patient Monitor 009-002927-00
C12 Cable, ACGO Valve Status 009-002940-00
C13 Cable, Internal AG Module 009-003131-00
C14 Cable, Display 009-000973-00
C15
0631 inverter control high-voltage lines (old)
0632 screen backlight output cable (new)
009-000974-00 (old)
009-006731-00 (new)
C16
0631 inverter cable B (old)
0635 screen LED backlight input cable (new)
009-000988-00 (old)
009-006382-00 (new)
C17 Cable, Alarm 009-000976-00
C18 Cable, Touch Screen 009-000978-00
C19 Cable, Encoder Board 009-002932-00
C20 Cable, Display Lighting 009-000986-00
C21 Cable, Top Lighting A 009-000982-00
C22 Cable, O2 Pressure Switch 0621-20-69588
C24 2-pin O2 Sensor Pedestal 801-0631-00067-00
C25 Cable, Circuit Switch 0621-20-78593
C26 Cable, Sodalime Canister Switch Cable 009-000987-00
C28 Cable, Breathing System 009-002928-00
C29 Cable, BFCS Position Switch 009-002930-00
C30 Cable, Total Flowmeter Backlight 009-002931-00
C31 Cable, Flowmeter Switch Signal 009-002929-00
C32 Cable, Backup Needle Valve Switch(without N2O) 009-005146-00
C34 Cable, Flow Sensor 009-002481-01
C35 Cable, Flowmeter 3 way Valve B 009-002937-00
C37 Cable, Ventilator 009-000979-00
C39 Cable, Three Way Valve(ACGO) 009-002592-00
No. Description P/N
