A7™ Ser
vice Manual
046-006272-00
3 - 31
Periodic Maintenance
Functional T
ests
FIGURE 3-37
Calibration Fr
ont Control P
anel - Pressure Button
b.
Gas Settings: Press the
Setup button, select
Setti
ng->ENTER->Gas Settings->MODIFY
->Gas
Ty
pe
-
>O
2
.
FIGURE 3-38
Calibration Front Contr
ol P
a
nel - Gas Settings
c.
Selec
t BACK->BACK-> BACK.
190
192
