Disassemble the Assemblies
Repair and Disassembly
6 - 12
046-006272-00
A7™ Ser
vice Manual
6.2.1.13
Remov
e the Three
-wa
y V
alve Assembly
1.
O
pen the service door
.
2.
Unplug the tube
s from the thr
ee
-way valve
assembly
, and disconnect the cables.
FIGURE 6-18
3.
Unscrew the
four scr
ews from the slide on the le
ft side of the main u
nit to remov
e the slide.
FIGURE 6-19
369
