Disassemble the Assemblies
Repair and Disassembly
6 - 44
046-006272-00
A7™ Ser
vice Manual
3.
Unplug the re
lated cables fr
om the touchscreen contr
ol board.
FIGURE 6-95
4.
Unscrew the
11 screws ar
ound the display back
plane and then rem
ove the display backplane.
FIGURE 6-96
5.
Slightly lift the touch screen off the displa
y front cover t
o
r
emove the touch scr
een.
FIGURE 6-97
