Disassemble the Assemblies
Repair and Disassembly
6 - 56
046-006272-00
A7™ Ser
vice Manual
6.2.8.8
Remo
ve the Needle V
alve Extension Mechanism
1.
Remove the pane
l of the pressur
e gauge and refe
r to 6.2.8.
2.
Unscrew the
four scr
ews to remo
ve the needle valv
e extension mechanism and the needle
valve module.
FIGURE 6-122
3.
Unscrew the 4 screws t
o remov
e the
needle v
alve extensio
n mechanism.
FIGURE 6-123
413
415
