Mindray A7 Service Manual

Introduction Replacement Parts
7 - 4 046-006272-00 A7™ Service Manual
9
N2O high pressure gauge assembly (A7)(must be
ordered together with the copper tube)
115-024851-00 and 115-033639-00
10
Air high pressure gauge assembly (A7)(must be
ordered together with the copper tube)
115-024852-00 and 115-033638-00
11
O2 high pressure gauge assembly (A7)(must be
ordered together with the copper tube)
115-024850-00 and 115-033637-00
12 N2O supply pressure gauge assembly (A7) 115-024848-00
13 Air supply pressure gauge assembly (A7) 115-024849-00
14 O2 supply pressure gauge assembly (A7) 115-024847-00
15 System switch knob 801-0631-00012-00
16 Backup vaporizer mounting manifold 801-0631-00076-00
17
Vaporizer mounting manifold 801-0631-00024-00
Three Vaporizer Mounting Manifold 115-020218-00
18 Pressure gauge panel assembly FRU
115-023184-00 (FDA)
115-023185-00(Canadian)
19 O2 cable plug cap 043-003033-00
20 O2 sensor cover assembly 115-016523-00
21 O2 Flush Button
043-002980-00 (FDA)
043-002981-00 (Canadian)
22 A-Series Handrail 042-002357-00
23 Drawer Handle 801-0631-00140-00
24 Vacuum Suction Tube Fixing Clamp 043-003125-00
25 Front cover of main unit 043-002207-00
26 Top cover screw paster 047-007458-00
27 Entire table 115-036455-00
28 Display panel 043-002982-01
/ Linear rail 032-000504-00
FIG.NO. DESCRIPTION PART NUMBER
