Mindray A7

A7™ Service Manual 046-006272-00 7 - 5
Replacement Parts Introduction
FIG.NO. DESCRIPTION PART NUMBER
18 Service door(A7) 115-021094-00
19 O2 cylinder yoke assembly (A7) 115-014476-02
20 N2O cylinder yoke assembly (A7) 115-014477-02
21 Air cylinder yoke assembly (A7) 115-014478-02
22 Caster assembly (right) 115-016956-00
23 Caster assembly (left) 115-016955-00
24 AGSS transfer tube 801-0631-00074-00
25 AGSS assembly FRU 115-023175-00
26
Vacuum suction liquid collection bottle bracket assembly (A7
Canadian)
115-017947-00
27 Overfill protection cup assembly 115-018131-00
28 Work surface cover plate assembly FRU 801-0631-00120-00
29 Yoke Panel 043-003140-00
30 Rear panel of hardware box 115-015377-00
31 Top deck assembly 115-017037-00
32 Dust filter 045-000241-00
33 Colder fitting 082-001206-00
