A7™ Service Manual 046-006272-00 7 - 7
Replacement Parts Introduction
FIG.NO. DESCRIPTION PART NUMBER
1 N2O regulator assembly 801-0631-00086-00
2 O2&Air regulator assembly 801-0631-00087-00
3 EFCS system 115-013502-00
4 Back pressure valve 115-040040-00
5 3-way valve assembly 115-015898-00
6
Lithium battery 11.1V 4500mAh LI23S002A
material package
115-018012-00
7 N2O supply inlet assembly (A7/DISS) 115-014825-00
8 Air supply inlet assembly (A7/DISS) 115-014826-00
9 O2 supply inlet assembly (DISS) 115-014827-00
10
Pipeline negative pressure inlet assembly
(DISS)
115-018133-00
11 System switch assembly (A7) 115-017877-00
12 Indicator light board PCBA 051-001257-00
13 Pressure gauge tube (left) (O2) 115-033637-00
14 Pressure gauge tube (middle) (Air) 115-033638-00
15 Pressure gauge tube (right) (N2O) 115-033639-00
16 BFCS drive assembly 115-029847-00
17 Gas mixer assembly(A7) 115-016781-00
18 Gas module rack 115-016480-00
19 Fan 12V 40*40*20mm 6.3CFM 18dB 024-000407-00
20
BFCS assembly (FDA) 115-030000-00
BFCS assembly (Canadian) 115-030001-00
21 Gas module 115-016575-00
/ Sampling return quick connector 115-015457-00
22 Output bracket for the monther board(VGA) 115-040634-00
