Mindray A7

A7™ Service Manual 046-006272-00 7 - 21
Replacement Parts Introduction
7.1.2.15 Base Assembly (A7)
FIG.NO. DESCRIPTION PART NUMBER
1 Spare brake assembly (new color) 115-016692-00
2 Connector of the Brake 801-0631-00095-00
3 Indicator Drive Plate 801-0631-00072-00
4 Principal Axis of the Brake 801-0631-00096-00
5 Base of Chasis Assembly 115-016691-00
1
2
3
4
5
