5-38 Image Optimization
View Curved VOI
To define a ROI, please remove the useless data as to reduce the volume data and
shorten the time for image storing, processing and reconstruction.
About the probes
A 2D imaging probe can be applied for Smart 3D imaging, however, to realize Static 3D imaging,
4D imaging, STIC, iPage, SCV, CMPR, Color 3D or Niche, a volume probe should be selected.
MPR
MPR represents three different views of 3D image.
In the quad display format view, the screen displays 3 MPRs (A, B and C) and the 3D image.
On the touch screen, the current window’s icon is highlighted; as shown in the following, A window is
the currently activated window.
A, B, C sectional images are corresponding to the following sections of 3D image
