5-106 Image Optimization
To display phases for the selected view(s)
1. To include a phase or view for display, select the leftmost, gray box to the left of each required phase
and/or view.
The system inserts a checkmark into each selected gray box.
2. To exclude a phase or view from display, select the blue box to the left of each required phase and/or
view.
The system inserts a red X into each selected box, like .
3. Select [Display Selected] on the touch screen.
The system displays the selected phases for each selected view side by side.
To display all views for a specific phase:
Select the phase label (for example, Rest).
To display all phases for a specific view:
Select the view label (for example, PLAX).
The system displays all phases for the selected view.
To display a loop in full-screen format:
1. Double-click the loop to display in full-screen format.
2. Double-click the loop again to display the loop in its initial size, select the loop again.
Description of review/WMS mode keys (keys with the same function as in select mode are not
described below):
Key Description
Review/WMS
Perform side-by-side comparison of the same views at different stages (PLAX,
PSAX, A4C, A2C at “Rest” compared to PLAX, PSAX, A4C, A2C “Post-
Exercise”). Clips are synchronized.
Selection: On, Off
Under [Text] "Off” status, when you select one stage, all view loops are displayed
on the screen; when you select one view, all loops of the same view in different
stages will be displayed on the screen.
Set [Text ] to “On”, the system will select loops of first two views of the first two
stages to display automatically. If you choose [Previous], then loops of the next
two views of the first stages will be displayed. If you click [Next], loops of the first
two views in the 3
rd
and 4
th
stage will be displayed.
In the meantime, if you choose one stage, loops of all views under this stage will
be displayed on the screen (4 at most), and choosing one view will lead to loops
of this view in different stages be displayed (4 at most).
Displays loops of all the stages and views selected.
5.15.4.2 Wall Motion Scoring
The WMS-Report lists user-assigned wall motion scores and associated data.
The Wall Motion Score (WMS) measurement is an application prepared for assisting in stress echo
semi-quantitative evaluations of abnormalities with left ventricular wall motion or changes in wall
thickness. The left ventricle is divided into segments for scoring to evaluate the degree of abnormality
from the sum of the scores in each segment using the motion of the walls of the entire left ventricle.
You can assign wall motion scores to specific portions within each view (representative loop). You can
also assign a normal wall motion score (WMS) to the currently selected view or to all displayed views.
Two methods of chamber segment division, ASE 16 and ASE 17, are supported. In addition, each
segment has 3 kinds of scoring method: 4, 5 and 7 points. Select through the [Scoring] control on the
touch screen.
