12-14 Setup
The iStorage screen is as follows:
Name Description
Service Name The name of the iStorage service.
IP Address IP address of the iStorage service device.
Port Port for transmitting.
Connect Click to verify connection.
Add Click to add the Network service to the service list.
Update To save the changed parameters.
Delete Click to delete the selected service from the service list.
Add an iStorage service
1. Set the iStorage server properties as described above.
2. Click [Add] to add the service to the Service list.
Modify a network service
1. Select the service to be updated in the service list.
2. You can see properties in the Configure Service area.
3. Modify the parameters and click [Update] to update the setting.
12.8.3 MedSight Preset
You can set environment for MedSight here and then use the MedSight function by mobile phone or
tablet computers. See MedSight manual for details.
12.8.4 Q-Path Preset
See Chapter 10.10 Q-Path for details.
