Service Manual 0070-10-0556-02 3 - 11
Isometric Drawings and Part List Rear Housing Assembly
FIGURE 3-6 Rear Housing Assembly (Lithium-Ion battery configuration)
SCALE 0.750
10
10a
(0212-12-0609)
2 PLACES
14
ALIGN HOLE
IN ITEM 21 (BRACKET) WITH
HOLE IN ITEM 1 (HOUSING)
3
1
(0212-12-0603)
2 PLACES
ALIGN UNUSED
TERMINAL AS SHOWN
ATTACH CONNECTOR PART
OF ITEM 14 TO J13
OF ITEM 12 (SEE SHEET 3)
ATTACH CONNECTOR PART
OF ITEM 10 TO J3 OF
ITEM 7
21
REF
28
REF
1
14
21
4
REF
6
28
23
(0012-12-0605)
5 PLACES
28
REF
REF
REF
(0212-12-0603)
2 PLACES
ATTACH CONNECTOR PART
OF ITEM 38 TO J21 OF
ITEM 12
2 PLACES
SEE DETAIL B
(0212-12-0603)
REF
38
85
CLEAN
SURFACE OF HOUSING
WITH
ISOPROPYL ALCOHOL AND
LET DRY. THEN
REMOVE RELEASE
LINER
FROM CLAMP AND INSTALL
ONTO
HOUSING.
FOR LITHIUM-ION ONLY
24
6
7
ATTACH CONNECTOR PART
0F ITEM 7 TO J8
OF ITEM 12 (SEE SHEET 3)
DETAIL B
SCALE 0.750
ORIENT FAN LABEL
SIDE DOWN WITH
CABLE EXIT AS
SHOWN
(0212-12-0607)
3 PLACES
(0012-00-1231)
LITHIUM-ION
BATTERY HOLDER
ROUTE
CABLE THRU
CABLE
CLAMP
AS
SHOWN
CONNECT
TO
POWER SUPPLY
LOCATE
CABLE CLAMP
AS
SHOWN OPENING
THIS
SIDE
9
28
3
10
9
6
7
24
21
1
14
6
28
23
38
1
21
28
14
4
10a
80
