Signum 3 Ex
Neutral Measurement Application Z nM
53
Example:
Measuring 25 m of electrical cable�
Settings (dierent from the factory settings):
Setup: Application 1: Neutral Measurement
Setup: Printout, PRTPROT 7�6�
then select the menu line items of your choice
1�) Place empty container on the
platform�
)
2�) Tare the scale�
Note: If the automatic tare
function is enabled, you do
not need to press the ) key
to tare the platform; the tare
weight is saved automatically
when you place the container
on the platform
248
3�) Enter the weight of 1 meter of
cable using the keypad (in this
example, 248 g)
O
4�) Save the value entered as the
reference weight
5�) Place the desired amount
ofcable in the container
Read the result
p
6�) Print the results
nRef + 1 o see:
wRef + 0.248 kg Conguring Printouts
G# + 6.794 kg
T + 0.541 kg
N + 6.253 kg
Qnt 25 o
--------------------
Neutral Measurement Application Z nM
