4- 26 Mx-Series Manual
of the grease after
greasing.
 Y-axis Linear Slide checking and greasing
Periodic checking and greasing is required for the Y-axis Linear Slide.
Make sure to unplug the
machine for the
worker’s safety.
1. Unplug the machine.
2. Turn off the circuit breaker (MCCB) for the X, Y gantry at the
rear of the machine.
3. Manually move the gantry to the + limit of Y-Beam. 4. Wipe grease and
dust from the Y-axis Linear Slide using a clean, soft cloth.
1) When the head unit
moves
in power off state, it
may experience load
by mechanical
characteristics. Since
this is not a
mechanical error, try to
move the head unit
slowly.
5. Manually move the gantry to the - limit of Y-Beam.
6. Wipe grease and dust from the Y-axis Linear Slide using a
clean soft cloth.
7. Apply a thin layer of grease along the longitudinal direction
of the linear slide.
2) Pay attention not to let
the
Linear Scale Tape or Linear
Scale Reading stained with
8. Turn on the circuit breaker (MCCB) for the X, Y gantry at the
rear of the machine.
