Chapter 5 Solutions for Errors 5-
7
5002
Front VSC placing
timeout.
Check the sensor or
air line.
Not applicable to Mx Series
6000
VSC board
communication fail
Not applicable to Mx Series
5-30
6001
The VSC board is not
ready to communicate.
Not applicable to Mx Series
5-30
6002
Rear VSC placing
timeout.
Check the sensor or
air line.
Not applicable to Mx Series
Error
Code
Message Description
Actions
References
7000
CONVEYOR
7000
Width adjustment
failed because board
is loaded.
Take out the board and adjust the
width.
5-46
7001
Belt driving error due
to the boards at the
inlet and the waiting
position
Take out the board and run the belt.
5-46
7002
The board fails to
move from
the inlet to the waiting
position.
Check that the step motor at the
entrance or the sensor at the waiting
position is working normally. In the
case of step motor error, check
whether both the step motors at the
entrance do not move or just one
motor does not work. If both the
motors do not work, check 24V
between pin5 and pin7 of TB CN11.
If only one motor does not work, check
the Molex 5557 connector connected
to the step motor and the contact of
TB, CN2,3.
5-46
7003-
7004
The board fails to
move from the waiting
position to the work
position.
Check that the step motor at the
entrance or the sensor at the waiting
position is working normally. In the
case of step motor error, check
whether both the step motors at the
entrance do not move or just one
motor does not work. If both the
motors do not work, check 24V
between pin5 and pin7 of TB CN11.
If only one motor does not work, check
the Molex 5557 connector connected
5-46
