5-8 Mx-Series Manual
to the step motor and the contact of
TB, CN4,5.
Error Code
Message Description
Actions
References
7005
The board fails to move
from the work position to
the outlet.
Check that the step motor at the
entrance or the sensor at the waiting
position is working normally. In the
case of step motor error, check
whether both the step motors at the
entrance do not move or just one
motor does not work. If both the
motors do not work, check 24V
between pin5 and pin7 of TB CN11.
If only one motor does not work, check
the Molex 5557 connector connected
to the step motor and the contact of
TB, CN4,5.
5-46
7006
A board exists between
the work position and
the outlet.
Check that the step motor at the
entrance or the sensor at the waiting
position is working normally. In the
case of step motor error, check
whether both the step motors at the
entrance do not move or just one
motor does not work. If both the
motors do not work, check 24V
between pin5 and pin7 of TB CN11.
If only one motor does not work, check
the Molex 5557 connector connected
to the step motor and the contact of
TB, CN6,7.
5-46
7007
The board fails to move
from the outlet to the
succeeding machine.
Check that the step motor at the
entrance or the sensor at the waiting
position is working normally. In the
case of step motor error, check
whether both the step motors at the
entrance do not move or just one
motor does not work. If both the
motors do not work, check 24V
between pin5 and pin7 of TB CN11.
If only one motor does not work, check
the Molex 5557 connector connected
to the step motor and the contact of
TB, CN6,7.
5-46
