Board size
Dual Lane : 50×50 ~ 410×250mm(16.1"*9.8"),t:0.4 ~ 5.0mm(About 3Kg)
Option : 640x250mm(25.2”*9.8”)
(Single Lane : 50×50 ~ 410×460mm(16.1"*18.1"),t:0.4 ~ 5.0mm(About 3Kg))
Components
Chip Size
0603 ~ 18×18 mm
0603 ~ 23×23 mm
Max Size
18mm (0.708”) square
32mm (0.71”) square (Single FOV)
50mm (1.97”) square (Multiple FOV)
Height
10mm
10mm/20mm
Number of components
(8mm feeder)
80 (Front : 40, Rear : 40)
Resolution
XY gantry : 0.001 mm
Head R : 0.044 deg
Head Z : 0.0035 mm
XY gantry : 0.001 mm
Head R : 0.044 deg
Head Z : 0.0035 mm
Precision R : 0.0055 deg
Precision Z : 0.0035mm
Transport height
37.5±0.5 inch SMEMA
910+30,-10mm(option)
Transport direction
Left to Right (Standard)
Right to Left (option)
Power requirements
3phase, 50/60 Hz
208V/220V/230V/240V
Option: 380V/400V/415V
Power consumption
About 3.0 KVA
Air consumption
About 300 Nl/min
About 240 Nl/min
Ambient Temperature & Humidity
15℃~32 ,℃ 30~75% (No dewdrops should form)
Weight (approx.)
1,800 Kg
Dimension (W×D×H),
Cover Only
1,202 ×1,900 × 1,500mm
