Test mode 0, Blink Port for 0.6 sec in
order
on
on
on
off
Test mode 1, Blink Port in order, all
ports turning on then shut-down
on
on
off
on
Test mode 2, Turns on Port in order and
turns it off
on
on
off
off
Test mode 3, All ports blink every 0.6
sec
on
off
on
on
Test mode 4, Turn all ports on
on
off
on
off
Test mode 5, Turn all ports off
on
off
off
on
Test mode 6, Applying Self -test
500usec delay
on
off
off
off
Test mode 7, Applying Self -test
250usec delay
off
on
on
on
Ordinary Operation ID# = 0
off
on
on
off
Ordinary Operation ID# = 1
off
on
off
on
Ordinary Operation D# = 2
off
on
off
off
Ordinary Operation ID# = 3
off
off
on
on
Ordinary Operation ID# = 4
off
off
on
off
Ordinary Operation ID# = 5
off
off
off
on
Ordinary Operation ID# = 6
off
off
off
off
Ordinary Operation ID# = 7
NX12PL Rotary S/W Configuration.(Last-PL Type)
ROTARY Switch Setup Condition
NO
Function
