Appendix E-3
0
Test mode 0, Blink Port for 0.6 sec in order
1
Test mode 1, Blink Port in order, all ports turning on then shut-down
2
Test mode 2, Turns on Port in order and turns it off
3
Test mode 3, All ports blink every 0.6 sec
4
Test mode 4, Turn all ports on
5
Test mode 5, Turn all ports off
6
Test mode 6, Applying Self -test 500usec delay
7
Test mode 7, Applying Self -test 250usec delay
8
Ordinary Operation ID# = 0
9
Ordinary Operation ID# = 1
A
Ordinary Operation D# = 2
B
Ordinary Operation ID# = 3
C
Ordinary Operation ID# = 4
D
Ordinary Operation ID# = 5
E
Ordinary Operation ID# = 6
F
Ordinary Operation ID# = 7
* MODULE DESIGN SHEET LIST
MODULE NO.
DESCRIPTION(Mx100&200)
Remark
00
Conveyor Sensor &ANC Solenoide Part
NXO2V B/D COMM
1
01
Lamp&Switch&Key Part
02
Conveyor Step Motor Part & SEMA
03
LSM&SVEN Part
04
ANC&Outlet Conv(Option) Part
05
Front Trolley(Option)
07
Rear Trolley(Option)
10
NXO2V B/D COMM 2
20
Left MSU (Option)
NXO2V B/D COMM 3
