3-2 Mx-Series Operation Manual
<Figure 3-3 가 Appearance of Mx200 and fork insertion position >
Conveyance
Since the sand paper is
disposable, do not reuse it
when moving the
equipment.
Devices such as
the keyboard,
mouse, etc. may
be delivered
without being
assembled
(separately
packed).
Therefore, these devices should be assembled before installing the
system.
Make sure to use a forklift with a fork of two meter (about six and
half feet) in length or a pallet truck for conveyance and installation.
The fork insertion position for Mx-Series is shown in Figure 3-3.
The arrow indicates the fork insertion direction.
Setup
1. Locate the equipment with a suitable forklift under
supervision of at the specified insertion position.
2. After moving the equipment to the installation position,
check the following before installation.
1) Using clean and dry cloth, remove foreign particles like dust
from the bottom of each foot plate and the floor on which the
foot plates will be placed.
2) Loosen the three bolts of each foot plate and check that the
foot can move freely. Make sure not to completely separate the
bolt from the foot plate. It is enough to rotate the bolt about two
and half rounds from the locked position.
3) Place #40 Sand Paper included in the packing list on the
floor below each plate.
To Next Page
