Chapter 3 Precautions for Production
3-7
Fails to strip off
vinyl.
Initial tension setting
Set the vinyl tight at initial setting
Operator
Any mechanical interruption
due deformed vinyl off part?
Remove vinyl before operating.
If the problem occurs again,
contact CS for service.
Operator
Type
Trouble
Check point
Solution
Performed
by
Excessive
picking error
Check the feeding position.
Re-teaching
Operator
Does the feeder slot matches
to the position in the
program?
Change the position / Check the
part
DB
Operator
Check the Z axis height
setting.
Error may increase if nozzle is tool
high. Z axis of emboss may be
higher than paper by 0.3~0.5.
Operator
Check the nozzle type.
Change nozzle
Operator
Check the shutter action.
Check the shutter link hinge
Replace the reel cover.
Operator
CS
Excessive error
in 1005/0603
Check the plate under the
reel cover shutter.
Replace the reel cover if the plate
is off
Operator
Check if Z axis height is
smaller than actual height.
Measure the Z height, add 0.1mm,
and enter the value.
Operator
Fails to pick up
the parts bigger
than 3225
Mount the feeder on the jig
or trolley, and check if there
is any interrupt between the
part and the window.
1) Apply 4mm pitch to 12mm
feeder. 2) File the interrupting
part.
Operator
Modified
feeder
Incorrect pitch
Check if the pitch set in the
display window matches
with the material pitch.
Reset the pitch.
Operator
Check if two springs in the
reel cover are properly
assembled, and if the reel
cover moves freely.
Adjust bolt for free movement of
reel cover. Remove any foreign
substance from the reel cover.
Operator
Excessive error
rate
Check if two or more chips
are exposed in the reel cover
window.
Adjust the chip protector so that
only a single chip is exposed.
Operator
