3 Setup
Contents
ADJUSTING HEIGHT OF C TROLLEY (P45EX, P40EX, P45CX)....................3-2
C TROLLEY(P45EX, P40EX, P45CX) PROGRAM SETUP...............................3-5
Adjusting height of C trolley (P45EX, P40EX, P45CX)
C trolley is designed to support PCB in 890~965mm from the line surface. Set the trolley height as
the following table in accordance with PCB height. You can set the height as described in the next
page.
No.
Korea, China, Japan and Southeast Asia
America/Europe (SMEMA : 37.5” ± 0.5”)
LINE LEVEL
HEIGHT SETTING
LINE LEVEL
HEIGHT SETTING
1
930
35
965
0
2
925
40
960
5
3
920
45
955
10
