Chapter 3 Installation
3-7
Pay attention not to
connect the ground
line to the neutral
line.
Power
Specification
and
Connection
Prior to
supplying
power to the
system, turn
off all
switches of
the system
and connect
the power
cable
provided by
Mirae
Corporation.
The Mx-Series
systems use
220 V AC
(10%, 3
phases,
50/60Hz) and
power consumption is 3.0 KVA or less.
(The system is delivered with the standard voltage 220V and other
voltages are available as options)
The cable to connect the main power of Mx-Series is presented at
the bottom right on the rear of the system.
* The Main switch (PC power) and the Run switch are at the front of
the system.
* If necessary, use a circuit breaker of 50 A or more.
* For customized specification, see the power specification
presented separately.
Grounding
The Mx-Series SMD placement system should always be grounded.
For grounding the Mx-Series SMD placement system, the green or
yellow-green line of the power cable provided by Mirae should be
connected to the factory ground.
※ Apply Class 3 Ground (100 Ohms and less) to the system.
Apply Special Class 3 Ground (less than 10 Ohms) to the system of
400 Volts or higher.
