<Step2> Push the connector plate with a screw driver or a wrench to disassemble the male connector
from
the female connector.
<Step4> Pull out the trolley.
Note1) The following photos show the Mx310 hand valve with P45EX. Refer to the next page for hand
valves with P45EX and P40EX.
Chapter 5 Precautions 5-5
Hand valve
Connector plate
