Chapter 3 Installation
3-15
Check the air pressure of compressed air input to the
machine. (Mandatory check item)
1) Ejector Type
- For a machine that does not use a vacuum pump, check
that the air supply line is properly leveled on the air panel at
the rear of the machine.
2) Vacuum Pump Type (Not applicable to Mx series)
- For a machine equipped with a vacuum pump, check that
the air supply line is properly set on the air panel at the
rear of the machine and also ensure that the value of the
vacuum level check sensor inside the machine is properly
set.
- To adjust the setting value, pull down the locking of the
adjustment bar and rotate it left or right.
Temperature/humidity (Mandatory check item)
- Check the room temperature and humidity at the plant.
Machine location
(Mandatory check item) -
Diagram the in-line
machine layout.
To Next Page
