3-16 Mx-Series Operation Manual
3. Foot size
910/950 mm
4. Foot height
For 910 /950
03
X,Y Gantry assembly
1.X Gantry moving
Manual moving
inspection
2.Y Gantry moving
04
Connector
1. Head connector
Visual
inspection
2. Power Box connector
3. VME Rack connector
4. MC & HC board connector
5. ANC & Conveyor connector
6. Amp Box connector
05
Internal assembly
1. Linear scale surface
Visual
inspection
2. Flat cable
3. Conveyor
4. Offset LED fixation
5. ANC fixation
6. Camera lens
7. AMP box cable protection rubber
8. X,Y cooling hose
9. Head air hose
10. Home sensor setting
11. Tray support replacement
12. Grease feeding to rack & pinion driving
unit
13. LM guide grease feeding
14. Belt Tension
06
Appearance
1. LCD monitor
Visual
inspection
2. Feeder base
3. Feeder clamp sensor block fixation
4. TF connection to the frame base
