Mirae Mx200 - Machine leveling check; X,Y Gantry assembly check

Chapter 3 Installation
3-17
5. Chamfering of hole edge
6. Gantry bolt fixation
07
Peripherals (TFU, SU)
1. Power and air connection
Visual
inspection
2. Assembly status (fixation, balance)
3. Motor and belt fixation
CIS 4 : Assembly check
When moving the
gantry, grip the vision
cover (black) of the
head with hand to
make it not move The
shaft fixation bracket
could be bent.
 Packing
list check
 Check
that the
equipment
has been
exactly
packed
according
to the
packing
list
prepared
upon
delivery
and check
the
optional
parts, if
any. 
Ensure
that there are no defects in the packing box of the equipment.
 Ensure that the machine is not affected by damage of the
packing box.
 Machine leveling check
 Machine leveling
Using a level meter, adjust the level offset between the front and
rear feeder bases at the top/bottom and the left/right to less than
30 ㎛.
 Pre/Post process balance
Check the balance of conveyor using a height gage.
 Foot size Record the foot size.
 Foot height
Adjust the machine level and record the foot height.
 X,Y Gantry assembly check
 X-Axis Gantry Moving
Check that there are no obstructions or cables in the way
while moving the X-Axis gantry left and right.  Y-Axis Gantry
Moving
Check that there are no obstructions or cables in the way while
moving the Y-Axis gantry left and right. When Amp power goes
off, the gantry can smoothly move for about 5 to 20 seconds and
then slows down (This is not a malfunction of the machine.)
 Connector check
 Head connector
