3-18 Mx-Series Operation Manual
- O
p
e
n
t
he head cover and check that there are no
loosened connectors in the HC board.
- Check the cable pins connected to the
connector.
- Ensure that no connectors are open due to cables being pressed
by air fitting.
- Ensure that there are no cables and air tubes damaged by
bracket and cover.
Power box connector
- Check the left/right connectors connected to the power box.
- Check the D-Sub Connector (right).
- AC line is at the right of the power box and DC line is at the left.
VME rack connector
- Check that the command connector (50 Pins) is locked firmly.
New machines have a bar pin type locking mechanism.
- Check that bolts are fixed on the encoder line.
- Check locking of the DC24V line connector at the bottom of the
VME rack.
MC & HC board connector
- Check locking of the inserted connector.
ANC & Conveyor connector
- Check that no sensor connectors are open or damaged.
Internal assembly check Check foreign
materials on the surface of linear scale
- Before turning power on, ensure that there is no oil on the scale
surface.
- Check that there are no scars on the scale surface. If there are, it
must be replaced. Flat cable assembly
- Check that the flat cables are assembled with an appropriate
isolation. Where flat cables are not separated properly, the
machine will sound ‘tick tick...’ when moving.
Conveyor status
- Check the conveyor assembly status.
- Check bolt loosening.
- Check the width of conveyor height guide (Spec. 16mm)
