1-2 MS1 (Multi-Tray Supply Unit) Operation Manual)
Setup
Environment The MS1 (Multi-Tray Supply Unit) is attached to the main frame of the
Mx series system.
Check where the MS1 will be mounted.
The figure below shows where to install the MS1.
(The main frame below is the Mx series main frame.)
1. Floor
The machine should be installed on a rigid floor that doesn’t vibrate.
The floor should be kept as horizontal as possible.
2. Temperature
15℃∼ ℃ 18
3. Humidity
30% 75%∼
Humidity should be kept below 45% to prevent dewdrops from
forming on the machine.
4.Vibration Mx-Series Base Frame MS1 Assembly Hole
< Figure 1-1 가 MS1 mounting position >
To Next Page
