Mirae Mx200 - Connect the harness cable

1-4 MS1 (Multi-Tray Supply Unit) Operation Manual)
MS1-L
MS1-R
2) After mounting the MS1 on the Mx series main frame, connect the
harness cable between the Mx series system and the MS1.
 MSU-PWR - Tray feeder power cable
 MSU-COMM - Tray feeder signal cable
 MSU-AIR - Tray feeder air cable
(The figure below shows the connectors to connect the Mx series harness to the MS1.)
MSU-PWR
MSU-COMM
MSU-AIR
