4-16 Mx-Series Operation Manual
<Figure 4-9 Mx-Series upward camera>
As seen in <Table 4-2> and <Figure 4-8,9>, the head and the downward
camera are integrated into an assembly.
<
Figure 4-8 Mx-Series downward camera>
Downward
Camera
Upward Camera
