Installation
PINX 1 signal Basic access
BRI-S ext.
Cable cores PINX 2 signal, Basic rate
interface BRI-T
f f
e e
d d
Bus configuration
BRI-S ext. is subject to the conditions that apply to terminal interface BRI-S (see BRI-S terminal
interfaces).
Figure 28: Basic rate interface BRI-T, networked with leased-line or dial-up connection
Table 37: Cabling for basic rate interface BRI-T, networked with leased-line or dial-up connection
PINX1 signal,
basic rate
interface BRI-
T
Cable cores NT1 Network NT1 Cable cores PINX 2 signal,
basic rate
interface BRI-
T
c c c c
f f f f
e e e e
d d d d
See also
Chapter "Connections with basic accesses" in the PISN/QSIG Networking System Manual.
