7.1 BOOT FLOW CHART
*6700 can read aastra.cfg (not startup.cfg). 6900/6800 will read startup.cfg if it exists,
otherwise it will read aastra.cfg.
Configuration files may be created by MX-ONE Service Node Manager or be based on
MX-ONE Template files stored in MX-ONE under /etc/opt/eri_sn/aastraSIPphones .
Template files exists for aastra.cfg, startup.cfg, <phone model>.cfg; as for example
6867i.cfg and <mac>.cfg; <mac> is the unique mac address of a phone. The template
for aastra.cfg/startup.cfg are generic configuration, whereas <phone model>.cfg
contains key configuration; softkey or programmable keys.
:
Configuration of:
-IP address, mask W
-DNS servers
-Time server
-Time zone ofst
-Software server URI (opt 66,43)
Power up
LLDP
To get Voice VLAN
DHCP
?
SW-server configured?
Manually
configuration
N
Y
Connect to
SW-server
Recommended protocols:
http or https
Reboot
Get
security.tuz
This file contains the encrypted site
key. Use the anacrypt tool to create
security.tuz and encrypt the config
files.
?
File exists?
Get
aastra.tuz*
Get
<model>.tuz
Get
aastra.cfg*
Get
MD5 check sum
?
Get auxiliary
files
Done
Download
fw, reboot
Language files,
Certificates
Different firmware?
firmware
Check
No
Get
<MAC>.cfg
<model>.cfg
No
Get
<MAC>.tuz
802.1x
To get access to the LAN
