MITEL 6900, 6970, 6800, AND 6700 SIP TERMINALS FOR MIVOICE MX-ONE
51 26/1531-ANF 901 14 Uen S 2019-10-18
11.23 USING THE PHONE AS AN OPERATOR MEDIA DEVICE
(OMD)
Not applicable.
A telephone is called Operator Media Device when it is used for the speech together
with a operator work station application, for example CMG NOW Attendant.
11.24 CENTRAL STORAGE OF USER SPECIFIC DATA
The data the that follows the user for the Mitel 6900/6800/6700 family when logging on
to another phone is the data stored in MX-ONE, for example MNS, DMN, SCA keys
and the speed dial keys initiated from MX-ONE. The data locally stored in the phone
does not follow the user.
11.25 CONFIGURING THE DIFFSERV PARAMETER
Diffserv is a model for handling of priority, based on the type of service (TOS) field in
the IP packet heading.
The TOS value can be defined in the aastra.cfg/startup.cfg file and the parameter
names are: tos sip and tos rtp.
The default values are tos sip: 38 AF/(100110) and tos rtp: 46 EF/(101110)
For more information: see Administrator Guides for Mitel Models 6900, 6970, 6800,
6700 and 9000 Series IP SIP Phones.
11.26 SELECTION OF TRANSPORT ADDRESSES (PORT
NUMBERS)
The table below shows the default port numbers. The ports are possible to change via
the aastra.cfg/startup.cfg file. For more information, see Administrator Guides for
Mitel Models 6900, 6970, 6800, 6700 and 9000 Series IP SIP Phones.
Table 6 UDP/TCP default ports used by the phone
Type of
signalling Minimum Maximum Comment
RTP 3000 The first media stream, uses
3000. The second mediastream
uses 3002 and so on.
RTCP 3000+1 RTP port + 1
SIP 5060 5060
SIP secure port 5061 5061 When using the phone in SIP /
TLS mode.
MX-ONE Mitel XML
API port
22222
22222
Used in combination with http://
when configuring /Logon and
/Startup
MX-ONE Mitel XML
API secure port
22223
22223
Used in combination with https://
when configuring /Logon and
/Startup
