Mitel 6900 - DEFAULT KEY LAYOUT

MITEL 6900, 6970, 6800, AND 6700 SIP TERMINALS FOR MIVOICE MX-ONE
29 26/1531-ANF 901 14 Uen S 2019-10-18
Table 3 Number of keys on the phone key layout and in total
Expansion modules can be added to 6920, 6930, 6940, to the 6753, 6735/55, 6737/57
and 6739, as well as to 6865, 6867, 6869 and 6873.
11.13.2 DEFAULT KEY LAYOUT
This chapter shows the default key layout per model. The following system keys can
be changed or removed via MX-ONE Service Node Manager or via editing the model
specific configuration files.
• Services
• Local Directory
• Callers List
• Message Waiting
• Corporate Directory
If one of these functions is removed, it can be replaced by a key with another function
that shall be generic for all phones of a certain model. The following options are
possible to set:
• speeddial
• xml
Model Hard keys Soft keys Comment
6920 - 6 top, 4
bottom
20 top softkeys on 4 pages
18 bottom softkeys on 4 pages
6930 - 12 top, 5
bottom
44 top softkeys on 4 pages
24 bottom softkeys on 4 pages
6940 - 48 top,
x bottom
Touch-screen
48 top softkeys on 4 pages
24 bottom softkeys on 4 pages
6863 3 -
6865 8 -
6867 - 6 top, 4
bottom
20 top softkeys on 4 pages
18 bottom softkeys on 4 pages
6869 - 12 top, 5
bottom
44 top softkeys on 4 pages
24 bottom softkeys on 4 pages
6873 - 48 top,
x bottom
Touch-screen
48 top softkeys on 4 pages
24 bottom softkeys on 4 pages
6730/ 31 8 -
6739 - 12 55 softkeys on 5 pages
6753 6 This model must have an expansion module
if MNS, TNS (initiated from the PBX), DMN,
MCT, PEN shall be used.
6735/ 55 6 top 6 bottom 20 bottom softkeys on 4 pages.
6737/ 57 - 6 top, 6
bottom
20 bottom softkeys on 4 pages.
10 top softkeys on 2 pages.
