Mitel 6900 - CONFIGURATION AT RECORDING ON DEMAND

MITEL 6900, 6970, 6800, AND 6700 SIP TERMINALS FOR MIVOICE MX-ONE
61 26/1531-ANF 901 14 Uen S 2019-10-18
Recording destination beep defines if a beep shall be heard to notify that recording is
ongoing.
Sip services transport protocol. The following options exist:
• -1: (default), which means that the same protocol will be used as defined in the
parameter sip transport protocol parameter.
• 0: TCP/UDP
• 1: UDP
• 2: TCP
16.2 CONFIGURATION AT RECORDING ON DEMAND
The prerequisite is that the settings for active recording is done, see section 16.1
Configuration at Total Recording on page 60.
When the user has pressed the recording key an icon is shown in the display when the
phone has got a confirmation from the recording system that the recording has started.
The shortcut key for recording is initiated from the PBX.
The URI to the recording system that the telephone sends when the user presses the
recording key, can be defined in one of the following ways:
• MX-ONE command extension_key. The advantage is that in a free seating envi-
ronment, the recording key with the associated URI will follow the user (directory
number).
• Phone configuration file. If the recording key shall be generically available it
could make sense to define it as a system key per phone model (<model>.cfg).
In the second option, the recording key is defined as a key of the type xml with the URI
as parameter value. This example shows how keys are configured to work with the
recording system from the vendor ASC:
• Start recording:
http://192.105.88.152:8080/XVOIPService?page=START& OPN=$$SIPUSER-
NAME$$
The phone replaces $$SIPUSERNAME$$ with its registered directory number.
The http://<host>:<port>/ must match the recorder’s listening IP address and port
number.
• Stop recording:
http://192.105.88.152:8080/XVOIPService?page=STOP& OPN=$$SIPUSER-
NAME$$
