18 COMMUNICATING USING 1E FRAMES
18.4 Read and Write Device Memory
Test in bit units (random write) (command: 04)
Specify the devices and device numbers of bit devices (X, Y, M, etc.) in 1-point units randomly, and set/reset them.
Message format
The following shows the message format of the request data and response data of the command.
■Request data
There is no request data for this command.
■Response data
There is no response data for this command.
Data specified by request data
■Number of device points
Specify the number of points of the bit device to be set/reset. (Page 402 Number of device points)
■Fixed value
Fixed to '0'.
■Specified device
Specify the bit devices to be set/reset. (Page 397 Device codes and device numbers)
■ON/OFF specification
Specify set/reset.
ASCII code Binary code
Processing ASCII code Binary code
Reset
Set
Specified device
(first point)
ON/OFF
specification
(first point)
Specified device
(nth point)
ON/OFF
specification
(nth point)
Number of device
points
(n points)
Fixed value
0
30H
0
30H
00H
0
30H
0
30H
00H
0
30 H
1
31 H
01H
