4G6 ENGINE (E-W) -
Crankshaft, Flywheel and Drive Plate
11A-12-3
Crankshaft journal outside diameter Cylinder block
bearing bore
Crankshaft bearing Crankshaft bearing
for No. 3
Identification color Size mm Identification mark Identification mark or
color
Identification mark or
color
Yellow 56.994 - 57.000 0 1 or Green 0 or Black
1 2 or Yellow 1 or Green
2 1 or Green 2 or Yellow
None 56.988 - 56.994 0 2 or Yellow 1 or Green
1 3 or None 2 or Yellow
2 2 or Yellow 3 or None
White 56.982 - 56.988 0 3 or None 2 or Yellow
1 4 or Blue 3 or None
2 5 or Red 4 or Blue
For example, if the crankshaft journal outside diameter
ID color is “yellow” and cylinder block bearing bore ID
mark is “1”, select a bearing whose ID mark is “2” or
ID color is “yellow” for number 1, 2, 4 and 5, and a bearing
whose ID mark is “1” or ID color is “green” for number
3.
If there is no ID color paint on the crankshaft, measure
the journal outside diameter and select a bearing
appropriate for the measured value.
RevisedPWEE9616-A
E
Aug. 1998Mitsubishi Motors Corporation
Bearing bore size
identification mark
Bearing bore
identification
mark
Cylinder inner
diameter size
mark
Rear face of
cylinder block
Bottom of
cylinder block
No. 1 No. 2
No. 3
No. 4
No. 5
Crankshaft bearing size
identification mark or color
Identification
mark or color
