4G6 ENGINE <E-W> -
Specifications
11A-1-1
1. SPECIFICATIONS
SERVICE SPECIFICATIONS
Items Standard value Limit
Timing belt
Auto-tensioner rod projection length mm 12 -
Auto-tensioner rod pushed-in amount [when pushed with a force of 98
- 196 N] mm
1.0 or less -
Rocker arms and camshaft
Camshaft cam height mm 4G63
Intake 37.39 36.89
SOHC
Exhaust 37.14 36.64
4G64
Intake 37.39 36.89
SOHC
Exhaust 36.83 36.33
Lash adjuster leak down time
[diesel fuel at 15 - 20_C] seconds/mm
3 - 20/1.0 -
Camshaft journal outer diameter mm 45 -
Rocker arms and camshaft (GDI)
Camshaft cam height mm
Intake 35.79 35.29
Exhaust 37.14 36.64
Lash adjuster leak down time
[diesel fuel at 15 - 20_C] seconds/mm
3 - 20/1.0 -
Camshaft journal outer diameter mm 26 -
Cylinder head and valves
Cylinder head flatness of gasket surface mm Less than 0.05 0.2
Cylinder head grinding limit of gasket surface mm
Total resurfacing depth of both cylinder head and cylinder block
- 0.2
Cylinder head overall height mm
SOHC 120 -
GDI 132 -
Cylinder head bolt shank length mm - Maximum 99.4
Valve thickness of valve head (margin) mm SOHC
Intake 1.0 0.5
Exhaust 1.2 0.7
GDI
Intake 1.0 0.5
Exhaust 1.5 1.0
Valve overall height mm SOHC
Intake 112.30 111.80
Exhaust 114.11 113.61
GDI
Intake 105.5 105.0
Exhaust 105.7 105.2
Valve stem outer diameter mm 6.0 -
