4G6
ENGINE
(E
-
W)
-
Exhaust
Manifold
1
1A-7-1
7.
EXHAUST
MANIFOLD
REMOV
AL
AND
INST
ALLA
TION
(GALANT)
1
2
13
Nm
13
Nm
6
5
49
Nm
13
Nm
29
Nm
4
3
13
Nm
13
Nm
Removal
steps
"
A
A
1.
W
ater
outlet
fitting
2.
Heat
protector
(Multipoint
fuel
injection)
3.
Exhaust
manifold
cover
(Carburetor)
4.
Engine
hanger
5.
Exhaust
manifold
6.
Exhaust
manifold
gasket
Revised
PWEE9616-A
E
Aug.
1998
Mitsubishi
Motors
Corporation
57
59
