4G6 ENGINE <E-W> -
Specifications
11A-1-7
Items Nm
Heat protector 13
Exhaust manifold (M8) 29
Exhaust manifold (M10) 49
Water outlet fitting 13
Rocker arms and camshaft
Rocker cover 3.4
Rocker arm shaft 31
Rocker arms and camshafts (GDI)
Camshaft position sensor 8.8
Cover 9.8
Camshaft position sensing cylinder 21
Camshaft position sensing support 13
Beam camshaft cap 20
Cylinder head and valves
Cylinder head bolt
[Tighten to 78 Nm and then completely loosen before finally tightening with above procedure.]
20 + 90_ +90_
Front case, counterbalance shaft and oil pan
Drain plug 39
Oil pan 6.9
Oil level sensor (For Europe) 8.8
Stiffener (For Europe) 21
Oil screen 18
Oil pressure switch (4G63) 19
Oil pressure switch (4G64) 9.8
Relief plug 44
Oil filter bracket 18
Plug 23
Flange bolt 36
Oil pump cover bolt 16
Oil pump cover screw 9.8
Front case 23
Transmission stay (GDI engine) 21
Oil level gauge guide 12
RevisedPWEE9616-B
E
Aug. 1999Mitsubishi Motors Corporation
