FX-20P-E Handy programming panel Others Function 10
10-23
Module mode operation condition
• Press the [OTHER] or [CLEAR] key to return to the others mode menu display.
PLC status Memory attached to module
Write from HPP to
module
Either status (RUN or STOP)
and either memory type
(In the FX
0
/FX
0S
Series
PLC, each operation is
available only in the STOP
status.)
EEPROM
*1
EPROM
*2
*1 The write-protect
switch is OFF.
*2 The EPROM is
already erased.
*3 The EPROM is
already written.
Read from module
to HPP
EEPROM EPROM
*3
Verify between
HPP and module
EEPROM EPROM
OFFLINE MODE FX
1.ONLINE MODE
2.PROGRAM CHECK
3.HPP
↔
FX
In the step 2)
Display example
In the step 5)
1)
2)
3)
OTHER
Key operation
Start up the HPP
in the offline mode.
7
[ROM WRITER]
HPP
→
ROM
HPP
←
ROM
HPP : ROM
ERASE CHECK
GO4)
5)
GO6)
GO7)
Select "MODULE".
Or put the cursor on "MODULE", then press the [GO]
key.
Select the transfer direction.
.
.
