FX-20P-E Handy programming panel Write 5
5-4
Contact instructions other than LD, LDI, AND, ANI, OR an ORI (Ver 4.00 and later)
Instruction Key operation
LDP [LD] [P/I]
→
[Device symbol] [Device No.]
→
[GO]
LDF [LD] [F]
→
[Device symbol] [Device No.]
→
[GO]
ANDP [AND] [P/I]
→
[Device symbol] [Device No.]
→
[GO]
ANDF [AND] [F]
→
[Device symbol] [Device No.]
→
[GO]
ORP [OR] [P/I]
→
[Device symbol] [Device No.]
→
[GO]
ORF [OR] [F]
→
[Device symbol] [Device No.]
→
[GO]
INV [NOP] [P/I]
→
[GO]
Comparison
contact instruction
Comparison contact instructions can be entered in the same way as application
instructions. Refer to 5.3.
